LS500DT41P 4 in 1 Boiling Hot Water Tap Installation Guide

[2025-08-23] | By Xiamen Smart Water Technology Co., Ltd. Allen Huang

How to Install a 4-in-1 Boiling Water Tap?

LS500DT41P is a 4 in 1 pull-down multifunctional mechanical tap with Swan spout, supplying boiling water, filtered water, and domestic hot &cold water in three water ways.

Our LS500DT41P instant boiling water tap installation guide is easy to follow. DIY or get a plumber to help. Find out how to install 4 in 1 boiling water tap.
In this article, you can see exactly how each piece fits together.

Tools and hardware required

• Safety Goggles
• Phillips Screwdriver
• Adjustable Wrench
• Plumbers Tape
• Flashlight

Verify that the hole size in the countertop is correct

Before beginning the installation of this product, ensure all parts are present. Compare parts with the Package Contents section. If any part is missing or damaged, do not attempt to install the product.

Faucet Model Number: LS500DT41P

NO.	Description	QTY
A	Faucet	1
B	Spray Head	1
C	Screw Stem	1
D	Counter-weight	1
E	Triangle Cushion	1
F	Rubber Washer	1
G	Metal Washer	1
H	Mounting Nut	1
I	Wrench	1
J	Three-way Connector	1
K	Supply hose from filter to tap ④	1
L	Supply hose from tap (filtered) to hot tank ⑤	1
M	Outlet hose from tap (domestic hot/cold water) to four-way quick connector ⑦	1
N	Outlet hose from tap (filtered) to four-way connector ⑧	1
O	Hot water supply hose ②	1
P	Cold water supply hose ①	1
Q	Pull down hose ⑨	1
R	Supply hose from three-way connector to filter ⑥	1
S	Supply hose from hot tank to four-way quick connector ③	1
T	Three-way connector	1
U	Three-way connector	1



NO.	Description	QTY
1	Instant Hot Water Dispenser	1
2	Power Cord	1

Filter specified and look may be different to the below.



NO.	Description	QTY
1	Filtration System	1
2	pex pipe	1

• Shut off the water supply

• Taking the faucet from packaging box and position seven hoses into mounting hole one by one. See Fig.1

• Position seven hoses through the triangel cushion(E) firstly, then place the rubber washer(F) and metal washer(G) through the screw stem(C) and fixed by mounting nut(H). See Fig.2

Please note: Pass the 3 hoses with nuts and pull-down hose FIRSTLY and then pass 4 hoses without nuts to facilitate installation

• Adjusting the faucet at correct direction, and tighten the mounting nut(H) with wrench (I). See Fig.3

• Install the three-way connector (J) to the cold water angel valve and connect the cold water supply hose (P) (with label ① /blue color) to one side of three-way connector (J). Connect the hot supply hose (O) (with label  ②/orange color) to hot water valve with an adjustable wrench. See Fig.4

• Connect the supply hose (R) (with label  ⑥/blue color) to the other side of three-way connector (J) and filter. Connect supply hose (K) (with label ④ /green color) to the filter. the See Fig.5

• Connect the pull-down hose (Q) (with label ⑨/white color) with four-way connector (T), and mount the counter-weight (D) on the hose with mark label. Please note that location pin of pull-down hose must align with location hole of four-way connector. If you fit the location pin difficulty, please change direction to align. See Fig.6.

• Connect the outlet hose (M) (with label ⑦/white color) and outlet hose (N) (with label ⑧/white color) to the four-way connector (T). See Fig.7

• Connect the supply hose (L) (with label ⑤/green color) with hot tank. Connect the outlet hose (S) (with label ③/red color) to the hot tank and one side of four-way connector (T). See Fig.8

• Put in order all hoses under counter to avoid disorder, and install the counter-weight (D) to the pull-down hose (Q). Leave enough space for pull-down hose to avoid influencing the function of pull-down. See Fig.9

• Turn on the hot/cold water angle valve and check every joints leakage. See Fig.10

• Sliding out the pick on the left round handle and turning the round handle clockwise at the same time, it will come out with the boiled and filtered water.  And turning the round handle counter-clockwise, it will come out with the cold and filtered water.

Our LS500DT41P 4-in-1 boiling water taps are simple to install if you have a toolbox and some basic DIY skills. However, if you are unsure or lack experience, we recommend seeking assistance from a qualified plumbing or electrical professional. This ensures a smooth installation and greatly reduces the risk of any issues.

If you encounter any difficulties during installation, feel free to contact us for free, no-obligation advice.

Contact now
