Instant Boiling Water Tap Installation Guide

[2025-08-23] | By Xiamen Smart Water Technology Co., Ltd. Allen Huang

How to Install a 4-in-1 Boiling Water Tap?

Boiling water taps have revolutionised the modern kitchen, drastically cutting down on the time it takes to complete everyday tasks and chores.
Our 4 in 1 boiling water tap supplies：

• Boiled water
• Filtered Water
• Ambient hot water
• Ambient cold water

Our 4 in 1 instant boiling water tap installation guide is easy to follow. DIY or get a plumber to help. Find out how to install 4 in 1 boiling water tap.
In this article, you can see exactly how each piece fits together.

Tools and hardware required

• Safety Goggles
• Phillips Screwdriver
• Adjustable Wrench
• Plumbers Tape
• Flashlight

Verify that the hole size in the countertop is correct

Before beginning the installation of this product, ensure all parts are present. Compare parts with the Package Contents section. If any part is missing or damaged, do not attempt to install the product.

4 in 1 Hot Water Tap Gold

Faucet Model Number: LS500MT41-01C





NO.	Description	QTY
A	Faucet	1
B	Rubber Washer	1
C	Rubber Gasket	1
D	Metal Washer	1
E	Mounting Nut	1
F	Three-way connector	1
G	Drinking Water Supply Hose ⑥	1
H	Hot Water Supply Hose ②	1
I	Cold Water Supply Hose ①	1
J	Drinking Water Outlet Hose ④	1
K	Boiling water Supply hose ⑤	1
L	Boiling water outlet hose ③	1

Filter specified and look may be different to the below.     Carbon Filter For Hot Water Tap

• Shut off the water supply

• Insert the rubber washer (B) over the hoses into the faucet shank, and mount the faucet on the basin. See Fig.1

• Slide the rubber gasket (C) first, the metal washer (D) secondly, then the mounting nut (E) over the hoses onto the stem, and hand-tighten
  them firmly. See Fig.2

    Please note: Pass the 4 hoses with nuts FIRST and then pass 1 tubes without nuts to facilitate installation.

• Use a Phillips head screwdriver to thread the 2 screws. See Fig.3

• Connect the Three-way connector (F) onto the Cold water valves. Connect the cold supply hose (I) (with label ①) onto the one side of the Three-way connector. Secure the connection with an adjustable wrench. See Fig.4

• Connect the Hot supply hose (H) (with label ②) onto the matching Hot water valves and secure the connection with an adjustable wrench. See Fig.5



• Connect the Drinking Water Supply Hose (G) (with label ⑥) onto the other side of the Threeway connector, and secure the connection with an adjustable wrench.

    Fit the other end of the hose (G) into the filter housing inlet. See Fig.6

• Fit Drinking Water Outlet Hose (J) (with label ④) into the filter housing outlet. See Fig.7

• Connect the boiling water Supply hose (K) (with label ⑤) onto the inlet of the boiling water tank indicated blue, secure the connection with an adjustable wrench. See Fig.8

• Connect the boiling water outlet hose (L) (with label ③) onto the outlet of the boiling water tank indicated Red, secure the connection with an adjustable wrench. See Fig.9

• Turn on the water supply and check the water connections for leaks. Test systems for leaks, and purge system. Run a minimum of 20 litres of water through the tank to remove any air.

• Then the installation is completed. Hang the plastic aerator wrench (M) on one of the hoses for future use. Plug tank into electrical outlet and switch unit on, power indicator will flash.

Our 4 in 1 boiling water taps are easy to install for those with a toolbox and a basic knowledge of DIY, however, for those who are unsure or lack experience, we advise seeking the help of a plumbing or electrical professional. They can make the process straightforward and drastically reduce the chances of a faulty installation.

If you have any trouble installing your tap, you can always drop us a line for free, no-obligation advice.
